NEC's PA1505UL-W (white cabinet) is a 14,000-lumen (Center: 15,000lm) LCD laser projector with advanced professional installation features for higher education and corporate users. With its multitude of digital inputs, connection to any computer or high definition device is possible. Enjoy design and installation flexibility with a complete line of optional motorized lenses (lens shift, focus and zoom), roll free installation capabilities. The HDBaseT input provides a single connection for uncompressed full HD digital video, audio, ethernet power and various control signals. HDBaseT Repeater allows cascading of the signal for edge-blending or stacking applications.

  • 4K Ready - Display stunning 4K 60P content using NEC’s proprietary high performance video processing/scaling chip from “Ultra HD Blu-ray” and “4K TV broadcasting” without the loss of critical details.
  • Learning of basic control of competitors product reducing the need for reprogramming of a control system. (call NEC for complete list)
  • Integrated software applications such as AMX Beacon, Crestron Roomview, Extron XTP and PJ link allow for complete interactivity and control.
  • 14,000-lumen (Center: 15,000lm) brightness provides brilliant images in most high ambient lighting situations.
  • ProAssist™ is software for controlling the projector and adjusting the projected image on the screen from a computer via a network. It allows necessary adjustments to be carried out easily when combining several projectors together to project a large screen in a classroom, meeting room, auditorium or other large space.

Primary Lenses

Motorized Zoom Lens 0.86-1.25:1 (NP53ZL), Motorized Zoom Lens 1.24-2.01:1 (NP54ZL), Motorized Zoom Lens 1.98-3.95:1 (NP55ZL)

Lens Adjustment Functions

Motorized focus, zoom, horizontal/vertical shift, light shutter (dowser) / Range of shift is dependent on lens

Supported Screen Size (maximum)

60 to 500 in./ 1.5 to 12.7m, NP53ZL, NP54ZL, NP55ZL

Additional Features

  • 4K Ready
  • Motorized Lenses
  • Manual Keystone Correction
  • Quick power on
  • ECO Mode Technology
  • DiCom Simulation
  • NaViSet Administrator 2
  • Quick power-off
  • Advanced AccuBlend
  • AutoSense
  • ProAssist Software


Cornerstone Correction

Allows for horizontal, vertical and diagonal image correction for aligned images even when the projector is set up at an angle to the screen.

Roll-Free Installation

Allows the projector to be rotated freely (360°) in order to point up or down depending on the installation requirements.

Variable Audio Out

Adjusts the volume of an external speaker system using the projector's remote control.

4K Ready

Display stunning 4K content using NEC’s proprietary high performance video processing/scaling chip without the loss of critical details.

Built-in Wall Color Correction

Presets provide for adaptive color tone correction to display properly on non-white surfaces.

Dual HDMI inputs (with HDCP)

Ensure quick switching between presentations and allows for simultaneous digital connections of high-definition sources, such as Blu-ray players, cable boxes, satellite receivers and computers

Lens Shift

Vertical and horizontal lens shift enables flexible projector placement.

Power Management

Enables projector to automatically turn off when an incoming signal is not detected from any of the inputs.

Crestron Roomview

Provides unified management, including the ability to switch the power on and off for multiple projectors connected to a network.

Motorized Zoom and Focus

Simplifies installation and operation by easily adjusting the lens through the remote control.

Quick Startup and Quick Power-Off

Allows users to begin presenting within 3 to 4 seconds and allows immediate power off with no cooling required after shutdown to ensure efficient energy usage.


Intuitively syncs the projector with most computer signals and features one-touch image optimization.

Portrait Mode

Ability to install a projector in its side to create a 10:16 portrait image

Virtual Remote

Used over the VGA cable to control the projector directly from a computer without the need for additional control cables.

Output Terminals
Audio Out: Stereo Mini Jack
Input Terminals
RGB4(digital):3G SDI (SMPTE ST 424M / SMPTE 292M)
RGB3(digital):HDBaseT w/HDCP (V1.4/2.2)
RGB2(digital):HDMI (V2.0) w/HDCP (V1.4/2.2)
RGB1(digital):HDMI (V2.0) w/HDCP (V1.4/2.2)
Signal Compatibility/Connectivity
External ControlRS-232, IR, Wired Remote, HDBaseT, DDC/CI, RJ-45, USB (USB 2.0)
Sync Compatibility Separate Sync / Composite Sync / Sync on G
Macintosh Signal CompatibilityYes
PC Signal CompatibilityVGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA, Quad HD
SD/HD Video Signal Compatibility480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 4K
Supported Video StandardsNTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM
Synchronization Range
Vertical 50-120Hz
Horizontal (Analog/Digital)24-153kHz
Contrast Ratio (typical)3,000,000:1 (with Dynamic Contrast)
Brightness (maximum)15000 Center Lumens
Brightness (typical) 14000 Lumens
Maximum Resolution 4K 4096 x 2160
Native ResolutionWUXGA 1920x1200
Aspect Ratio16X10
Power Consumption (typical)
On960W / 855W / 0.4W / 0.15W (Normal/Silent Mode/Network Standby/Standby)
Input Current11.6A - 5.1A
Power Requirements100-240V AC, 50/60 Hz
Power Supply Voltage100-240V AC, 50/60 Hz
Dimensions (WxHxD)
Product:23.6 x 9.4 x 19.3 in. / 599 x 238 x 490 mm
External: 23.6 x 9.4 x 19.3 in. / 599 x 238 x 490 mm
Shipping:29.1 x 15.0 x 24.8 in. / 739 x 382 x 629 mm
Net Weight:63.3 lbs. / 28.7 kg
Shipping: 78.3 lbs. / 35.5 kg
Environmental Conditions
Operating Temperature32-113°F / 0-45°C
Operating Altitude0 to 2600 m (8,500 ft)
Storage Humidity20% - 80% (non-condensing)
Operating Humidity20 to 80% Humidity (Non-Condensing)
Storage Temperature 14-122°F / -10 50°C
Storage Altitude 0-12,000m / 0-39,370ft (above sea level)
Display Technology1.0" LCD w/ MLA
Light Output(Lumens) 15,000 Lumens
Light Source Life 20,000 hours
Throw Ratio0.86 to 1.25:1 Motorized Zoom Lens / 1.24 to 2.01:1 Motorized Zoom Lens / 1.98 to 3.95:1 Motorized Zoom Lens
Projector Angle5.8 to 18.1° tele / 11.4 to 25.8° wide
Keystone Correction+/- 40° horizontal, +/- 30° vertical
Focus: Motorized
F number, fnumber:(NP53ZL) F=1.8 to 2.24, f= 19.0 to 27.6mm, (NP54ZL) F=1.8 to 2.24, f= 27.7 to 44.9mm, (NP55ZL) F=1.84 to 2.58, f= 43.8 to 87.2mm
